National Aerospace Std - Drilled Shank Steel Bolt, Shear | NAS6604D15

• Thread Class: 3A
• Thread Direction: Right-Hand
• Thread Length: 0.425 Inches Nominal
• Fastener Length: 1.348 Inches Minimum And 1.378 Inches Maximum
• Head Style: Dished Hexagon
• Head Height: 0.125 Inches Minimum And 0.140 Inches Maximum
• Width Between Flats: 0.430 Inches Minimum And 0.439 Inches Maximum
• Grip Diameter: 0.2481 Inches Minimum And 0.2487 Inches Maximum
• Single Shear Strength: 95000 Pounds Per Square Inch
• Nominal Thread Diameter: 0.250 Inches
• Grip Length: 0.928 Inches Minimum And 0.948 Inches Maximum
• Thread Quantity Per Inch: 28
• Minimum Tensile Strength: 160000 Pounds Per Square Inch
• Material: Steel Comp 4340 Overall
• Material Document And Classification: Mil-S-5000 Assn Std Single Material Response Overall
• Surface Treatment: Cadmium Overall
• Thread Series Designator: Unjf
• Specification/Standard Data: 80205-NAS6604D15 Professional/Industrial Association Standard
